Specifications
| Product number | F2S72A |
|---|---|
| Ideal for | Boosting your productivity—this printer turns out quality color and black-and-white graphics at top speeds, with reliable performance job after job. |
| Functions | |
| PRINT SPECIFICATIONS | |
| Print technology | HP Thermal Inkjet |
| Print languages | HP-GL/2, HP-RTL, CALS G4 |
| Optional print languages | Adobe PostScript 3; Adobe PDF 1.7; TIFF; JPEG |
| Model size | 1524 mm |
| Guaranteed minimum line width | 0.067 mm (ISO/IEC 13660:2001(E)) |
| Guaranteed minimum line width footnote | Measured on HP Matte Film |
| Theoretical minimum line width | 0.02 mm (HP-GL/2 addressable) |
| Line accuracy | ±0.1% |
| Line accuracy note | ±0.1% of the specified vector length or ±0.2 mm (whichever greater) at 23ºC (73ºF), 50-60% relative humidity, on A0/E HP Matte Film in Best or Normal mode with HP Photo Inks |
| Color accuracy | Median < 1.25 dE2000, 95% of colors < 2.75 dE2000 |
| Color accuracy note | ICC absolute colorimetric accuracy on HP Premium Instant-dry Photo Paper with Original HP inks |
| Color Stability | < 1 dE2000 in less than 5 minutes |
| Color Stability Note | With HP Premium Instant-dry Gloss Photo Paper and Original HP inks, right after calibration |
| Print speed | 140 m²/hr |
| Print speed color image (normal, coated paper) | 26.3 m²/hr |
| Print speed color image (normal, glossy paper) | 19.7 m²/hr |
| Print speed color image (best, glossy paper) | 13.1 m²/hr |
| Print time color image ISO N5 (best, metric A1 glossy paper) | 3.2 min/page |
| Print time color image ISO N5 (draft, A1 coated paper) | 18 sec/page |
| Print time color image ISO N5 (normal metric A1 coated paper) | 1.5 min/page |
| Print time color image ISO N5 (normal metric A1 glossy paper) | 2.1 min/page |
| Maximum optical density (black) | 4.5 L* min/2.31 D |
| Print quality color (best) | Up to 2400 x 1200 optimized dpi |
| Maximum optical density footnote (black) | With HP Premium Instant-dry Gloss Photo Paper and Original HP inks |
| Non-printable area (roll media) | 5 x 5 x 5 x 5 mm |
| Print repeatability | Average < 0.5 dE2000, 95% of colors < 1.25 dE2000 |
| Print repeatability note | On HP Premium Instant-dry Gloss Photo Paper with Original HP inks, right after calibration |
| Printing path | Printer driver, HP Embedded Web Server, HP DesignJet Click printing software |
| Printer drivers included | HP-GL/2, HP-RTL drivers for Windows; PostScript Windows and Mac drivers with optional PostScript/PDF Upgrade Kit |
| Internal Storage | Standard, 320 GB |
| Memory | 64 GB (virtual) |
| CONNECTIVITY AND COMMUNICATIONS | |
| Connectivity, standard | Gigabit Ethernet (1000Base-T); EIO Jetdirect accessory slot |
| Connectivity, optional | HP Jetdirect EIO print servers |
| Network ready | Standard |
| HP ePrint capability | No |
| POWER | |
| Power Consumption | 270 watts (printing); < 48 watts (ready); < 5.3 watts (sleep); < 0.3 watts (off) |
| Power | Input voltage (auto ranging): 100-127 V (±10%), 5 A; 220-240 V (±10%), 3 A; 50/60 Hz (±3 Hz) |
| CARTRIDGES AND PRINTHEADS | |
| Number of print cartridges | 8 (chromatic red, magenta, yellow, light cyan, light gray, light magenta, matte black, photo black) |
| Print cartridge volume delivered | 775 ml |
| Print heads | 8 (chromatic red, magenta, yellow, light cyan, light gray, light magenta, matte black, photo black) |
| Print head nozzles | 2112 |
| Ink drop | 4 pl (lc, lm, lg, pK), 6 pl (R, M, Y, mK) |
| Ink types | Pigment-based |
| SUPPORTED PRINTING MEDIA | |
| Finished output handling | Roll feed; automatic cutter; take-up reel |
| Media types | Bond and coated paper, technical paper, film, photographic paper, proofing paper, backlit, self-adhesive, banner and sign, fabric, fine art printing material |
| Media sizes standard (metric rolls) | 279 to 1524-mm rolls |
| Media width, maximum | 1524 mm |
| Media weight, recommended | Up to 460 g/m² depending on media type |
| Media thickness | Up to 22 mil |
| Roll external diameter | 170 mm |
| Roll maximum input | 1 |
| Roll maximum weight | 25 kg |
| Supported Primary Applications | Posters; Banners; Mockups; Photos; Digital fine art; Proofs; Displays; POP/POS; Light boxes – film; Exhibition, event graphics |
| ENVIRONMENTAL | |
| Operating temperature range | 5 to 40ºC |
| Storage temperature range | -20 to 55ºC |
| Operating humidity range | 20 to 80% RH |
| Non-Operating Humidity Range | 20 to 80% RH |
| Acoustic power emissions | 7.0 B(A) |
| Acoustic power emissions (standby) | 5.5 B(A) |
| Acoustic pressure emissions | 53 dB(A) |
| Acoustic pressure emissions (standby) | 39 dB(A) |
| DIMENSIONS AND WEIGHT | |
| Dimensions without stand (W x D x H) | 2430 x 690 x 1370 mm |
| Package dimensions (W x D x H) | 2700 x 750 x 1200 mm |
| Weight | 190 kg |
| Package weight | 252 kg |
| BOX CONTENTS | |
| What’s in the box | HP DesignJet Z6800 Photo Production Printer; spindle; printheads; introductory ink cartridges; maintenance cartridge; printer stand; take-up reel; 3-in spindle adapter kit; quick reference guide; setup poster; startup software; power cord |
| Software included | Printer driver, HP DesignJet Click, HP DesignJet Utility including HP Color Center |
| WARRANTY | |
| Warranty | One-year limited hardware warranty |
| CERTIFICATION AND COMPLIANCE | |
| ENERGY STAR® certified | Yes |
| Electromagnetic Emission Standard | Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (MSIP) |
| Safety Approvals and Requirements | USA and Canada (CSA certified); EU (LVD and EN 60950-1 compliant); Russia (GOST); Singapore (PSB); China (CCC); Argentina (IRAM); Mexico (NYCE); Korea (KC) |
| OTHER | |
| Web address for additional information | http://www.hp.com/go/designjetz6800 |
| Accessories | HP DesignJet PostScript/PDF Upgrade Kit CQ745B, HP DesignJet 60-in Spindle CQ754A, HP Jetdirect 640n Print Server J8025A, HP SD Pro 44-in Scanner G6H50B, HP HD Pro 42-in Scanner G6H51B, HP SmartStream Preflight Manager L3J69AAE, HP SmartStream Preflight Manager One-Year Subscription L3J71AAE, HP SmartStream Print Controller for HP DesignJet Z6200/6600/6800 Production L3J79AAE, HP DesignJet 60-in Media Bin Q6714A, HP DesignJet User Maintenance Kit Q6715A |
| Services (Care Pack) | HP Installation Service with Network Setup H4518E; HP 2 year Next Business Day Onsite Support with Defective Media Retention U1ZS8E; HP 3 year Next Business Day Onsite Support with Defective Media Retention U1ZS9E; HP 5 year Next Business Day Onsite Support with Defective Media Retention U1ZT0E; HP 1 year Post Warranty, Next Business Day Onsite Support with Defective Media Retention U1ZT2PE; HP 2 year Post Warranty, Next Business Day Onsite Support with Defective Media Retention U1ZT1PE; HP Preventive Maintenance Service U1XV4E |
